Lipo Pouch Cell Lithium Polymer Battery
Quick Details
- Warranty:1year, 1 YEAR
- Place of Origin:Guangdong, China
- Brand Name:Newhop/OEM
- Model Number:LMO1380200C
- Battery Size:13mm*80mm*200mm
- Application:BOATS, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Scooters/e-bike/golfcart
- Certification:msds
- Weight:500g
- Product name:3.7v 20Ah lipo battery
- Type:Li-polymer
- Cycle life:80% DOD more than 1000 times
- Composed Type:Single cell
- OEM/ODM:Accepatable
- Discharge Cut-off Voltage:2.75-3.0V
- Charging Cut-off Voltage:4.2v
- Size:Customized
Product Description
|
Product Name
|
Shenzhen battery factory LMO1380200C 3.7v 20Ah lipo pouch cell lithium polymer battery 20000mah for 12v 24v 36v 48v 52v 20Ah battery pack
|
|
Material
|
NCM
|
|
Power
|
3.7v 20Ah 74Wh
|
|
Size
|
13mm*80mm*200mm
|
|
Charge
|
0.5C /1C (-10centi-degree to + 55 centi-degree)
|
|
discharge
|
Standard 10AMP 0.5C Max constant discharge 40AMP 2C;
Peak discharge 60AMP 3C 10seconds.
|
|
Weight
|
500g
|
|
Cycle life
|
80% DOD more than 2000 cycles.
|
|
KG Energy Density
|
208Wh/KG @1C @4.2v-2.75v@25 centi-degree
|
|
L Energy Density
|
480Wh/L @1C @4.2v-2.75v@25 centi-degree
|
|
Cycle life
|
more than 1000 cycles after 80% DOD
|
|
Cables/connectors/PCM
|
Yes,its accepted,tell our sales your requirements details.
|
|
Package
|
Plastic holder package and then into carton
|
