18650 Brand Cell 10ah 36V Lithium Ion Battery Pack for Ebike

Port:Shenzhen, China

Production Capacity:3000PCS/Day

Payment Terms:L/C, T/T, Western Union, Paypal

Model NO.:FB-36V10P

Rated Capacity:10ah(Customized)

Standard Voltage:36V

Usage:E-Bike

Electrolyte:Li-ion

Weight:3kg

  • Size Guide

    Size Guide

    SIZE CHEST WAIST HIPS
    XS 34 28 34
    S 36 30 36
    M 38 32 38
    L 40 34 40
    XL 42 36 42
    2XL 44 38 44
  • Delivery Return

    Delivery

    We ship to all 50 states, Washington DC.
    All orders are shipped with a UPS tracking number.
    Always free shipping for orders over US $200.
    During sale periods and promotions the delivery time may be longer than normal.

    Return

    Thembay will accept exchanges and returns of unworn and unwashed garments within 30 days of the date of purchase (14 days during the sales period), on presentation of the original till receipt at any store where the corresponding collection is available within the country of purchase.

    Your return will usually be processed within a week to a week and a half. We’ll send you a Return Notification email to notify you once the return has been completed.
    Please allow 1-3 business days for refunds to be received to the original form of payment once the return has been processed.

    Help

    • Give us a shout if you have any other questions and/or concerns.
    • Email: contact@mydomain.com
    • Phone: +1 (23) 456 789
  • Ask a Question

Free

Worldwide
Shopping

100%

Guaranteed
Satisfaction

30 Days

Guaranteed
Money Back

18650 brand cell 10ah 36v lithium ion battery pack for ebike


Product Parameter

ItemSpecification
Technical data:FB-36V10P
Chemistry:Li-ion/Lithium ion
No. of cells:18650 10S5P
Capacity:10Ah discharging at 0.2C
Nominal Voltage:36V
Standard charge voltage:42V±0.05V
Standard discharge voltage:30±0.05V
Impedance:≤ 150 mΩ
Norminal Charge Current:0.5C
Maximum Charge Current:<5Ah  (can be adjustable)
Maximum Discharge Current:<15Ah  (can be adjustable)
Maximum Pulse discharge current:≤ 35A (can be adjustable)
Charge end current:0.01C
Operation Temperature Range:Charge: 0~45ºC
Discharge: -20~60ºC
Storage Temperature:Less than 1 year: -20~25ºC
less than 3 months: -20~40ºC
Weight:Approx 2.5kg
Dimension:Length:Max. 495mm
Width:Max.   70mm
Thickness:Max. 38mm



Characteristics:

1. Extremely safe and stable chemistry: BMS or PCB built inside to protect the battery over charge and discharge.

2. Long life-cycle: 800 times cycle life.

3. Lighter and smaller: 1/3 weight of lead acid battery, 70% size/weight of Ni-MH/Ni-Cd battery.

4. Wide operating temperature: High temperature resistance(-20~60 degrees Celsius).

5. Steady performance: High power output, 1C continuous, 3C pulse for normal cells, Low self-discharge rate, less than 3% monthly.

6. No memory effects and highly efficient charge: It can be recharged anytime, no reduction of the capacity

7. Green product: Environment friendly, clean and green energy, no pollution on our environment.

8. Quality assurance:  CE/Rohs/MSDS/UN38.3/FCC certificates

    CE,ROHS UN38.3,TUV,KC etc…product certificates.


 Applications:

 1. Telephone switchboard, electric equipment and power instruments

 2. UPS, emergency application and medical devices

 3. Power transmission and transformer station and accident lighting

 4.  Fire fighting, safety device and alarm monitoring

 5.  Automatic office system

 6.  Radio communication system

 7.  Emergency lighting and car/ship starting system

 8.  Portable electric appliances and mining system

 9.  Traffic and navigation signal lamp

 10. Solar energy: solar street lights, solar LED lights
