18650 Brand Cell 10ah 36V Lithium Ion Battery Pack for Ebike
18650 Brand Cell 10ah 36V Lithium Ion Battery Pack for Ebike
Port:Shenzhen, China
Production Capacity:3000PCS/Day
Payment Terms:L/C, T/T, Western Union, Paypal
Model NO.:FB-36V10P
Rated Capacity:10ah(Customized)
Standard Voltage:36V
Usage:E-Bike
Electrolyte:Li-ion
Weight:3kg
-
Size Guide
Size Guide
SIZE CHEST WAIST HIPS XS 34 28 34 S 36 30 36 M 38 32 38 L 40 34 40 XL 42 36 42 2XL 44 38 44 -
Delivery Return
Delivery
We ship to all 50 states, Washington DC.
All orders are shipped with a UPS tracking number.
Always free shipping for orders over US $200.
During sale periods and promotions the delivery time may be longer than normal.Return
Thembay will accept exchanges and returns of unworn and unwashed garments within 30 days of the date of purchase (14 days during the sales period), on presentation of the original till receipt at any store where the corresponding collection is available within the country of purchase.
Your return will usually be processed within a week to a week and a half. We’ll send you a Return Notification email to notify you once the return has been completed.
Please allow 1-3 business days for refunds to be received to the original form of payment once the return has been processed.Help
- Give us a shout if you have any other questions and/or concerns.
- Email: contact@mydomain.com
- Phone: +1 (23) 456 789
-
Ask a Question
Ask a Question
18650 Brand Cell 10ah 36V Lithium Ion Battery Pack for Ebike
Free
Worldwide
Shopping
100%
Guaranteed
Satisfaction
30 Days
Guaranteed
Money Back
Product Parameter
| Item | Specification |
| Technical data: | FB-36V10P |
| Chemistry: | Li-ion/Lithium ion |
| No. of cells: | 18650 10S5P |
| Capacity: | 10Ah discharging at 0.2C |
| Nominal Voltage: | 36V |
| Standard charge voltage: | 42V±0.05V |
| Standard discharge voltage: | 30±0.05V |
| Impedance: | ≤ 150 mΩ |
| Norminal Charge Current: | 0.5C |
| Maximum Charge Current: | <5Ah (can be adjustable) |
| Maximum Discharge Current: | <15Ah (can be adjustable) |
| Maximum Pulse discharge current: | ≤ 35A (can be adjustable) |
| Charge end current: | 0.01C |
| Operation Temperature Range: | Charge: 0~45ºC |
| Discharge: -20~60ºC | |
| Storage Temperature: | Less than 1 year: -20~25ºC |
| less than 3 months: -20~40ºC | |
| Weight: | Approx 2.5kg |
| Dimension: | Length:Max. 495mm |
| Width:Max. 70mm | |
| Thickness:Max. 38mm |
Characteristics:
1. Extremely safe and stable chemistry: BMS or PCB built inside to protect the battery over charge and discharge.
2. Long life-cycle: 800 times cycle life.
3. Lighter and smaller: 1/3 weight of lead acid battery, 70% size/weight of Ni-MH/Ni-Cd battery.
4. Wide operating temperature: High temperature resistance(-20~60 degrees Celsius).
5. Steady performance: High power output, 1C continuous, 3C pulse for normal cells, Low self-discharge rate, less than 3% monthly.
6. No memory effects and highly efficient charge: It can be recharged anytime, no reduction of the capacity
7. Green product: Environment friendly, clean and green energy, no pollution on our environment.
8. Quality assurance: CE/Rohs/MSDS/UN38.3/FCC certificates
CE,ROHS UN38.3,TUV,KC etc…product certificates.
Applications:
1. Telephone switchboard, electric equipment and power instruments
2. UPS, emergency application and medical devices
3. Power transmission and transformer station and accident lighting
4. Fire fighting, safety device and alarm monitoring
5. Automatic office system
6. Radio communication system
7. Emergency lighting and car/ship starting system
8. Portable electric appliances and mining system
9. Traffic and navigation signal lamp
10. Solar energy: solar street lights, solar LED lights
